Beside to our constantly growing product range and latest developments, we also present you further reaching information around the issue of measurement technology.
Whether are they explanations in technical details, reports or descriptions of complex processes as well as current activities.
Thus, you always have an up-to-date overview.
Further on, we also provide the service of checking and calibrating sensors and measuring amplifiers in the future.
If you have any questions or individual wishes, please do not hesitate to contact us.
Also in the new year, besides our high-quality programme, we offer you individual customisation for your requirements. Whether it is the execution of necessary threads instead of through-holes, the painting in your company colour or the technically complex adaptation in design. Complete new developments for your application are just as readily carried out by us, which reflects our flexibility, especially in today's world.
As a small manufactory, we have maintained this performance capability, which our customers confirm with their satisfaction. With pleasure and competence, we advise you on site, to give you an understanding of the complex topic of sensor technology and to support you in your construction as well as testing projects. Stay tuned for news in 2022, your TEQFORT team.
12/2021 After a challenging year, which was characterized by hardship and uncertainty for many in the professional as well as in the private sphere, we would like to thank you in a very special way for the confidence you have placed in us.
We wish our Partners, their families and friends of TEQFORT GmbH a peaceful Christmas and a healthy start into the new year 2022.
We will also be taking a rest from 23/12/2021 to 09/01/2022 and will be back for you from 10/01/2022. Of course, we can be reached by e-mail at any time. We are looking forward to working with you again on interesting projects and new challenges.
11/2021 After a long information break, during which we were very active, we are very pleased to announce the positive completion of a major project. This project involved the delivery of over 80 sensors for dynamic and static strength tests on rail vehicle components, such as bogies and railway bodies. Furthermore, these transducers are used in various large-scale projects in the aviation and automotive sectors.
These sensors are our models FFB01-P, FTF01-P as well as FFT01, which we have manufactured in various load ranges and versions, such as two measurement outputs as well as with and without DAkkS calibrations.
We are very pleased that we were able to obtain this major order from a globally known and respected testing service provider, who also designs and manufactures test benches for various industries.
IMA Materialforschung und Anwendungstechnik GmbH, in short IMA Dresden, is the independent, accredited and certified test centre.
Through competent guidance and open communication, we have gained the trust of IMA Dresden as a permanent partner in such a way, that we have been commissioned with another project for multi-component special sensors, which we will report on in detail in the near future. TEQFORT - always there for you -
03/2021 Just as springtime
gives rise to something new in nature, TEQFORT once again offers you a new sensor series. With our model range FFS01-P for tension and compression loads we now cover small forces up to 500 N
nominal load. In addition to the small and flat design, the sensor is also characterized by its low weight of approx. 300 g.
The FFS01-P model is the right choice for all applications where precise
measurement with a small footprint and low weight are required. It does not matter whether it is used in the automotive sector, medical technology, development or research. Its hermetically
sealed design also contributes to its versatility. So, TEQFORT, always the right choice.
01/2021
Welcome to 2021 and enjoy the news we have in this year for you. As always, we are your partner in providing solutions for your tasks.
Your TEQFORT GmbH
12/2020 Christmas Season: Especially in these times the TEQFORT GmbH would like to thank all customers and friends who have not only ensured the persistence, but also the strengthening of our company by your support. With the whole TEQFORT team at our side, we have always been and will always be your contact for standard as well as special solutions.
In our digital epoch one is quickly subject to the misconception, that everything can be solved with information from the internet. But how quickly we realise in our daily work that a competent and personal contact is indispensable. Even for standard sensors, questions arise time and again, that can be answered most quickly by personal consultation or even on-site support. After all, this individual service creates a special relationship of trust which goes far beyond "selling" and creates a lasting partnership. Not profit at any price, but trust and consistency are the tenor of the time.
Therefore, we are looking forward to seeing you again soon, also on site, to advise and support you.
With this in mind, we wish you and your families, above all, health, a pleasant Christmas season and a good and confident start into the year 2021. From 23/12/2020 to 03/01/2021 we will also be resting and from 04/01/2021 we will be there for you again.
10/2020 Application: Intensive tests on bicycles and bicycle components!
Nowadays it is well known that extensive tests and fatigue strength investigations are carried out on almost all motorized and non-motorized vehicles in the automotive, aviation or railroad technology sectors.
A somewhat newer area is the testing of bicycles and bicycle parts. If you are a self-respecting manufacturer of high-quality bicycles and bicycle parts, there is no way around extensive testing in development and quality assurance. We as TEQFORT GmbH are pleased to contribute to product safety and supply our precision sensors to DHM Prüfsysteme in Clausthal-Zellerfeld, a specialist for testing and test bench construction, especially in this segment. In the picture you can see a test setup for testing handlebar-stem-combinations. Due to the way the load is applied with two force sensors, the handlebars can be loaded with force on both sides synchronously or asynchronously. This allows to run through different load spectra and to simulate various load conditions. High accuracy over the entire measuring range of the sensors is particularly important here. Due to the previous detailed examination of the requirements and the accompanying intensive consultation by TEQFORT GmbH, the DHM Prüfsysteme could be offered a precisely matching sensor with individual configuration. Thereby our customers receive the optimal sensor with the highest possible efficiency.
06/2020 Despite the current tense situation TEQFORT GmbH is not letting up and is pleased to announce the extension of the FFB01-P model range by two further load sizes, 1 kN and 2.5 kN. Inspired by customer requests and meanwhile very successfully tested in practice several times, these two force transducers now officially find their way into our product range.
TEQFORT is there for your task with pleasure.
02/2020 DEKRA tests with TEQFORT equipment
The IEC 60335-2-107:2017 specifies a test on battery-powered robotic lawnmowers. To meet the requirements of IEC 60335-2-107:2017, a maximum kinetic energy of 5 Joul may be applied to an obstacle (object, person, etc.) during an impact in automatic mode. The required measurement data are determined by means of a force sensor, behind which a specific measurement algorithm is used, and by repeating the process five times.
In addition to the necessary force sensor from our model series FFB01-P, TEQFORT GmbH also manufactured a complete testing device with linear bearing for the Dresden test laboratory of DEKRA Testing and Certification GmbH (Fig. 2). The mobility of the testing device as well as a support of mass discs to increase the weight, guarantee a maximum flexibility in the test setup and thus a high practical relevance of the tests. In addition, a correction of the relevant IEC standard was suggested, since in the current design (Fig. 1) a force shunt occur which cause a not negligible measurement uncertainty at the expected loads.
TEQFORT GmbH, competence and precision right from the start!
11/2019 Customer requirements increasing, ... but sometimes to smaller loads also. Therefore, the enlargement of our model range with our new TTT01-P torque sensor in the measuring range from
10 Nm to 500 Nm is now taking place. This extremely accurate torque sensor is suitable for use in all non-rotating areas of measurement and testing technology. Be it in the development or in the area of fatigue strength tests on components. Another outstanding feature is the possibility of direct combination with our sensor model FFB01-P to a force/torque system, which is also called Tension/Torsion combination. This type of combination takes place in the entire load range of the model series without any adapters, which could complicate the further assembly then. Optionally available bending measuring circuits (Mx and MY) thus provide a further step in the direction of multi-component measurement. Model TTT01 ...
05/2019 Also, this year the TEQFORT GmbH can record the "automotive testingexpo 2019" as a further success. The ideas of our new model FFB01-P, the well-known bending transducer, and the measuring amplifier EAW01, which can be accommodated both in the measuring line and directly in an enlarged connection housing of the sensor, were well received. Furthermore, some visitors from home and abroad were interested in our model 2FF01. This sensor is very well known in the field of tire uniformity measurement and TEQFORT GmbH offers this 2-component sensor in addition to the known versions in the American pound system also in concrete Newton loads (e.g. 10 kN / 5 kN). Herewith we provide you with all further information about the force sensor model FFB01-P as well as the measuring amplifier EAW01, so that you can inform yourself about the technical data. For questions we are happy to assist you. Model FFB01-P; Model EAW01; Model 2FF01 ...
MayTime - Exhibition time
Also, this year the TEQFORT GmbH participates again in the Automotive Testing Expo in Stuttgart and we present you from 21.05. - 23.05.2019 our latest developments.
In addition to enlargements and expansions of model series, our latest model, the force transducer series FFB01-P, has a very special focus.
The force sensor FFB01-P is based on the known principle of the bending ring and is characterized by its construction with a very high accuracy with a large bandwidth.
Furthermore, you will be introduced to our new measuring amplifier EAW01, which can be integrated in a measuring cable or directly on the sensor.
Visit us in hall 8, booth 8402 and we will gladly
explain more details about our products and
individual solutions.
03/2019 TEQFORT GmbH expand one of his model ranges again.
Customer inquiries and surveys revealed the need for renewed expansion
our FFT01-P sensors. We were happy to comply with the customer's request for even larger versions of the popular FFT01-P model series and have designed this sensor series up to
1000 kN. On request, however,
loads up to 3MN can be designed. Intermediate sizes can also be produced, whereby these have already been realized in 63 kN.
06/2018 TEQFORT expands model range. We have supplemented our model of the FTF01-P series with additional types of load. As a result of inquiries and projects, it became apparent that our customers like to have smaller and medium loads within this model range.
Of course, we have fulfilled this requirement and can now offer you force transducers from 25 kN. Thus, not only do we achieve a variety of 21 different load sizes at an accuracy of 0,05%, but also the ability to offer sensors with low insensitivity to bending moment and eccentricity for small and medium loads. This is e.g. also very interesting for measurements in the agricultural sector. Model FTF01 ...
06/2018 Another sensor model complements our product range.
In some applications, it may happen that a flat force transducer, due to its diameter, can not be used.
Here our model FTT01 is used, which can be integrated well with its column shape and with its two internal threads, or customized adapters, in pushrods. The model FTF01 is characterized by a small design and by a 100% fatigue strength. Through wedge disks and threaded bolts, a version with an external thread can be generated in this model. Model FTT01 ...
04/2018 And again, the product range is being expanded by TEQFORT
GmbH.
With the model FFF01-P we take the requirements of our customers into account, to offer a force sensor with central flange. Especially at higher loads, the central flange offers the advantage of
much easier assembling. In many cases of replacement requirements for test stands, the existing adapters are already designed for the hole pattern of this flange. Therefore, the exchange is
particularly easy. Furthermore, it is not necessary in dynamically operating test benches to preload the system in which the sensor is installed, which is unavoidable in threaded designs often.
The application for this sensor series can be found in the automotive and rail technology sectors as well as in the aerospace and wind power industries. Take a closer look at our new model range FFF01-P under Products/Sensors Force. Model FFF01 ...
01/2018 With the New Year, we start directly with the introduction of a further model range in our range
of products. Since we were addressed by our customers to a 2-component sensor for the tire industry, we are happy to follow the request of such transducer and developed a so-called X-Y
sensor. This transducer combines the both forces X and Y, in a compact design and high accuracy, in one body and is also provided for dynamic applications. The picture shows the typical application for the tire uniformity test, wich is a
100% online check during the tire production.
TEQFORT - benefit from our multifaced
Know-How!
